Hydraulic label die punching machine
Hydraulic label die punching machine

Hydraulic label die punching machine

Model NO.

Hydraulic label die punching machine

This machine specially designed for die punching the paper label, special format label,foil, plastic sheet and other products which need to die cut.

With the feature of big pressure,high precision ,efficiency and safety for operation, this equipment extensively use for printing and packaging industry.

Main technical data:

maximum cutting size90*65mm100*100mm150*150mm190*190mm270*270mm340*340mm
minimum cutting size87*57mm55*40mm95*60mm105*75mm120*120mm150*150mm

stack height

cutting pressure12KN16KN30KN40KN50KN50KN
working speed99mm/s76mm/s66mm/s65mm/s65mm/s65mm/s
net weight285kg300kg360kg560kg900kg1140kg
package size1680*650*1230mm1700*650*1230mm1800*700*1360mm1850*740*1400mm1900*840*1400mm1950*850*1500mm
