KSQ-C Face Cutting Knife Sharpener

Model NO.: KSQ-C
Price:: USD 9600.00-10600.00 / set
Delivery: FOB
Minimum order quantity: 1 set
Supply Ability: 30 set / Month
Country of Origin: Ningbo or Shanghai

Quantity:

Product Description

KSQ-C Face Cutting Knife Sharpener

KSQ-C Face knife sharpener machine is a kind of relatively high automatic machine in KSQ series.It is setup on the basis of A type with new processes of eletromagnetic sucking disc, PLC control system,frequency conversion adjustment,ect.It improves the serviceability and automatization greatly ,and can rub and pare different materials of blade domestic or imported.It’s the ideal associated machine for imported paper cutting machine and combined binding line,such as Polar,Martini,Kohlbooth,ect.

Main collocation:

Imported frequency exchanger

Siemens PLC control step motor

Centralized oil supply system

Schneider electric

Electromagnetic worktable

Special grinding head eleric machine

Features:

The journey adopts frequency conversion stepless timing electric machine drive and aerial steel wires transmission with steady run and nonshock during alter directions

Adopt Siements PLC controlled stepper to realize 0.01mm precision of automatic feeding

Adopt concentrated oil –supply system for machine tool lubrication,convenient and effective maintenance

Adopt integrated casting constuction,high stiffness and low deformation

Use YT flexible belt,reduce the shock and friction,prolong the working life

Install the mobile adjustor behind the grinding head

Main Specifications:

Model	Max.frinding length	The rotate Angle of table	Speed of journey	The rotate speed of grinding wheel	Total power of machine tool	Overall weight	Overall dimension of machine tool
KSQ-1700C	1700mm	0-90°	3-10m/min	1400N/min	3.8kw	1500kg	2450 x 900 x 1500 mm
KSQ-2200C	2200mm					2000kg	2950 x 900 x 1500 mm
KSQ-2700C	2700mm					2500kg	3450 x 900 x 1500 mm
