Semi-automatic book saddle stitching machine
Semi-automatic book saddle stitching machine

Semi-automatic book saddle stitching machine

Model NO.

Semi-automatic Book Saddle Stitching Machine

This semi-automatic book wire saddle stitching machine applies to stitch all kinds presswork of notebooks, ads, magazines, books and directions. Generally, it has two nail head to bind and at most it has four nail head to bind. No matter single united book or double united book can be stapled one time. With Hohner stitcher head and photo sensor for control the feed, this machine is very reliable type and has been exported 60 countries.

Fetures of saddle stitcher:

1. This machine adopts photoelectric control and monitor protection, automatic counting and jamming stop functions.

2. It adopts the frequency conversion speed regulation system, and it is stable and easy to regulate speed.

3. When pages are combined by hands, it can automatically adhere, bind and reception.

Technical Data:

Max binding size

450×305 mm

Min binding size

127×89 mm

Binding wideness

0.2-4 mm

Binding speed

30-90 book/minute

Steel wire to use

25# ,26#

Power of electric use



370 kg

Overall size

2380×1040×1420 mm
