Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine
Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine

Automatic High Speed Self Adhesive Label Paper Rolls Slitter Rewinder Machine

Model NO.
KSQE-1300
Quantity:

KSQE-1300 Automatic High Speed Self-adhesive Label Paper Rolls Slitter Rewinder Machine

This self adhesive paper slitter machine mainly designed for jumbo roll paper slitting and rewinding, fit for self adhesive paper or plastic film etc.

Main technical parameter

Maximum unwinding diameter

φ1200mm

Maximum rewinding diameter

φ600mm

Unwinding width range

400-1300mm

Slitting width

40-1300mm

Paper core diameter

3″

Maximum machine speed

400m/min

Max rewinding speed

30-400m/min

Max slitting speed

30-380m/min

Deviation correct precision

≤0.50mm

Tension settting range

2-30kg

Unwinding motor power

5.5kw

Rewinding motor power

7.5kw

Drawing motor power

3kw

Total power of machine

18kw

Machine dimension

3600 (L) x 4500 (W) x 1850mm (H)

Machine weight

About 3500kg

Slitting material

Film and laminated film12-350um,PE PVC 40um-150um, adhesive paper,paper,etc.

Machine color

Grey white (other colors can choose)
