Model NO.
FP-320
Delivery:
FOB
Minimum order quantity:
1 set
Supply Ability:
20 set / Month
Country of Origin:
Shanghai or Ningbo
Quantity:

FP-320 Flexo Printing Machine

This flexo printing press is fit for flexo printing of label paper, commercial forms; computer typing paper, film etc, the printing quality is high and cost effective for the plate. This flexo printing equipment use water based ink, it is green equipment so widely accepted by printing and packaging industry.

Features:

1. Use high precision ceramic anilox cylinder for ink transfer

2. Unwinding adopts magnetic brake and Mitsubishi tension controller

3. Rewinding adopts magnetic clutch and reliable tension controller

4. Printing unit 360° plate register adjustment

5. IR dryer for each printing unit

6. The anilox roller will be separated with plate roller and still keeping low speed running after machine stopped

7. Imported frequency inverter for speed control

8. With laminating unit and rotary die cutting unit

9. Optional parts: UV dryer, web guide, turn-bar, rotary die cutting station, video camera etc.

10. 320mm, 450mm, 620mm, 820mm width available, other size can be special made

Main specifications:

Model

FP-320

Printing speed

50m/min

Printing color number

2

Max. web width

320mm

Max. printing width

310mm

Max. unwinding diameter

600mm

Max. rewinding diameter

600mm

Printing repeat length

175-320mm

Precision of color register

±0.1mm

Overall dimensions

2X1.1X1.9M

Weight

About 1600kg

Main equipments:

Description

Quantity and Brand

Printing roller

3sets

Anilox roller

1set

Mounting machine

1set

Unwind tension controller

1pc, Mitsubishi , Japan

Transducer

2pcs, Mitsbishi , Japan

Rewind tension controller

1pc, Made in china

Magnetic power brake

2pc, Ningxia , china

Electromagnetism valve

1pc, SMC, Japan

Inverter

1 pc, TECO, Taiwan

Contactor

Schneider , France

Center relay

Schneider , France

Temperature

Yuyao , China

All Switches

Schneider , France

Other low-pressure wiring

Schneider , France

Standard configuration

3sets of printing rollers

1set of anilox roller

Mounting machine

IR Dryer

Turn bar

Lamination system

One rotary die-cutting station

Unwinder tension controller ( Mitsubishi)

Rewinder tension controller (China brand)

Options:

UV dryer:

Web-guiding system :

Rewinder tension controller (Mitsubishi):

Video inspecting system :
