Middle Speed Tea Coffee Paper Cup Making Machine
Middle Speed Tea Coffee Paper Cup Making Machine

Middle Speed Tea Coffee Paper Cup Making Machine

Model NO.
JBZ-22D
Quantity:

JBZ-22D Middle Speed Tea Coffee Paper Cup Making Machine

1. The whole steel body, sandwich paper feeding design and the style of lubricating system ensure the long-term normal and stable work of the equipment.
2. Short distance double vertical axis combined with advanced high-precision cylinder open CAM drive, so that each station high-speed operation accurate.
3. The single-blade groove CAM structure combined with the seesaw jacking rod design can make the high-speed paper feeding accurate in place.
4. Delicate original ¢490 mm die wheel design, make the equipment working load lighter, faster.
5. Scientific and reasonable machinery is suitable for travel design, can be used on the premise of changing the mold, so that the product production range is 6oz-22oz, paper thickness 170-350g.

Main technical parameter

Model

JZB-22D

Cup size

6~22oz

Raw material

160~350g/㎡(one side PE coated paper)

Capacity

60-90pcs/min
Top mouth diameter

φ60mm-φ90mm

Bottom diameter

φ40mm-φ70mm
Height

60mm-180mm

Bottom depth

Depth 5mm-10mm

Main motor power

1.5kw

Energy consumption

6-6.5kw/h

Total power

11.5kw

Air source

0.4m³/min,0.5-0.8Mpa

Machine weight

2200kg
Dimension(L*W*H)

1750×1350×1850mm  (Host)

1100×810×1750mm  (Receiving table)

Packing size

1910×1570×2000mm  (Host)

1250×950×1950mm  (Receiving table)
