KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine
KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine
KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine
KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine
KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine

KL-5545 Automatic L- sealer + BSD-4520 Shrink Packing Machine

Model NO.
KL-5545+BSD-4520
Delivery:
FOB
Minimum order quantity:
1 set
Supply Ability:
10 set / Day
Country of Origin:
ningbo/shanghai
Quantity:
Product Description

KL-5545 automatic L-type sealer

characteristic

1.The sealing knife adopts copper alloy sprayed with Teflon, it won't stick film, sealing fastness, without smoke, non-pollution. Horizontal and vertical sealing knife adopt whole connecting without gap, the film won't break. Sealing frame adopts high quality alloy steel, the sealing quality is stable, frame difficult to be damaged.

2. The machine has entire automatically system, it equipped with sensors can reach high speed automatic working.

3. It is convenient to adjust according to different sizes products, just adjust the handle wheel can reach it, operation is easy.

4. it can be connected with production

5. it has protection function to avoid sealing product wrong and ensure the safety of operator

BSD-4520 shrink tunnel characteristic

1 It adopts Schneider AC contactor, high-power Solid state booster and intelligent temperature controller to make temperature system more accurate, prolong the working life.

2 It adopts solid roller conveyor, the rollers wrapped with high temperature silica gel tube. It can stand heavy product and difficult

To wear (you also can choose net type conveyor)

3 It adopts high-power fan motor to ensure enough strong wind to reach perfect packing effect.

4 Inside wall adopts stainless steel, it has fast temperature transfer, even heating, low energy consumption, long working life characteristics.

Application

This machine is widely used in foodstuff, drinks, printing, books, pharmaceutical, floor, hardware and other industries shrink packaging. It is suit for POF, PE, PVC and other packaging material.

Specification

Model

KL5545

BSD4520

Max packing size(mm)

L450×W350×H100

W450×H200

Max sealing size(mm

L550×W450

/

PowerKW

1.30

8.5

Capacity

0-20 pcs/min

0-15 pcs/min

Voltage

220V 50/60HZ

380V 50/60HZ

Sealing temperature

160—240 depends on thickness of film and environment temperature

160—240 depends on thickness of film and environment temperature

Thickness of film(mm)

0.015-0.10

0.0150.10

Air pressure(Kg/cm2))

5

5

Packing material

POF PVC

POF PVC

Machine weight(kg)

320

210

Machine size(mm

L1700×W900×H1400

L1700×W900×H1400
