KZD-400ZF High speed four side seal center seal plastic bag making machine
KZD-400ZF High speed four side seal center seal plastic bag making machine

KZD-400ZF High speed four side seal center seal plastic bag making machine

Model NO.
USD 45,000.00-65,000.00 / set
Minimum order quantity:
1 set
Supply Ability:
50 set / Year
Country of Origin:
  • Place of Origin:CN;ZHE
  • Weight:3500KG
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Dimension(L*W*H):About 12 x 1.5 X 1.6m
  • Model Number:KZD-400ZF
  • Brand Name:KINGSUN
  • Warranty:one year
  • Computerized:YES
  • Power(W):45kw
  • Condition:New
  • Voltage:380V, or special made
  • Bag Type:Zipper Bag
  • Material:plastic
  • Certification:ISO9001
  • Machine Type:Bag Forming Machine
  • Product name:plastic bag making machine

KZD-400ZF Center seal,side sealing,4 side sealing high speed automatic platic bag making machine

Material: various laminated films.
Roll folding: max width: 850mm, max diameter: 600mm.

Bagging speed: 180 parts/min (mechanical design speed), approx. <40m/min.
Bagging width: max width 400mm.
Bagging length: 30-400mm, When the bag length is above 400mm,it will change into multiple conveyances.
Notes: The actual operation speed will reduce for the reason of difference of the bag type and material.
Unwind mode
Fabrication: put the warp beam horizontally.
Control: tension is automatically controlled by floating roller, magnetic powder brake displacement sensor.
Driving mode
Feeding traction: Driven by altemating servo motor.
Upper & lower sealing press: Altemating electrical machinery or altemating servo motor.
Heat seal: speed of heat seal, duration of heat seal, proportion of heat seal acce- leration etc.(main servomotor)
Temperature: 0-300,contact-free automatic control, CRT displaying.
Automatic count: presetting is available.
Punching device: time can be preset, continuous or interval punching is available.
Working mode: printing, non-printing.

There is KZD-400ZF,KZD-500ZF and KZD-600ZF model plastic bag making machinery.

Company Information

Wenzhou Kingsun Machinery Industrial Co.,ltd is China leading professional supplier and manufacturer of printing and packaging machines & materials. We provide a wide range of high quality equipment and service for printing and packaging industries, including post-press equipment such as flatbed automatic die cutter, hot foil stamping machine, folder gluer, paper guillotine, thermal laminator, flute laminator, slitter rewinder, paper sheeter, automatic case maker and label making machine such as flexo printing press, label die cutting machine, and flexible packaging equipment such as rotogravure printing machine, dry laminator, plastic bag making machine, center seal bag making machine, packing machine and other paper converting machinery etc. Our factories have 10-20 years of manufacturing experience, Kingsun company focus on R&D, quality control and after sale service, so we have the ability to provide high quality, reasonable priced products. Since so many years our products have been well accepted by customers from more than 65 countries.

Kingsun Company also boasts its 12 more years of experience, we deliver goods worldwide, our teams are all university graduated and constantly with professional training with energetic and positive attitude

Kingsun Company has 15 more manufacturing factory bases, each factory focus on only one or a few kind of specific printing and packaging machines production, as a result, we have the ability to meet different needs from different buyers, this way can take advantage of our machinery group and each of factory can play its own marketing or manufacturing strengths.

Our team has accumulated huge experience for this industries, we also have established a specialized after-sales service team and R&D team, so that we can create more value for our buyers.

Looking forward to work with you to create a more successful business together!
